Name: NGS Vertical Control

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This data contains a set of geodetic control stations maintained by the National Geodetic Survey. Each geodetic control station in this dataset has either a precise Latitude/Longitude used for horizontal control or a precise Orthometric Height used for vertical control, or both. The National Geodetic Survey (NGS) serves as the Nation's depository for geodetic data. The NGS distributes geodetic data worldwide to a variety of users. These geodetic data include the final results of geodetic surveys, software programs to format, compute, verify, and adjust original survey observations or to convert values from one geodetic datum to another, and publications that describe how to obtain and use Geodetic Data products and services.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 0d5fd4fb8cb94bc4b62cfda3df8e8c7b

Copyright Text: NOAA, National Geodetic Survey and cooperating organizations

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1420133.4513880871
YMin: 41789.674338407815
XMax: 971927.3655305803
YMax: 2480843.977650486
Spatial Reference: 2881  (2881)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: VERT_ORDER
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1
  Label: 1st Order
  Description: N/A
  Symbol:

• Value: 2
  Label: 2nd Order
  Description: N/A
  Symbol:

• Value: 3
  Label: 3rd Order
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:
Label Placement: esriServerPointLabelPlacementAboveRight
Label Expression: [NAME]
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 80000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 5 )
• FeatureId ( type: esriFieldTypeSmallInteger, alias: FeatureId )
• DATA_DATE ( type: esriFieldTypeString, alias: DATA_DATE, length: 8 )
• DATA_SRCE ( type: esriFieldTypeString, alias: DATA_SRCE, length: 57 )
• PID ( type: esriFieldTypeString, alias: PID, length: 6 )
• NAME ( type: esriFieldTypeString, alias: NAME, length: 40 )
• HT_MOD ( type: esriFieldTypeString, alias: HT_MOD, length: 1 )
• CORS_ID ( type: esriFieldTypeString, alias: CORS_ID, length: 4 )
• PACS_SACS ( type: esriFieldTypeString, alias: PACS_SACS, length: 4 )
• STATE ( type: esriFieldTypeString, alias: STATE, length: 2 )
• COUNTY ( type: esriFieldTypeString, alias: COUNTY, length: 26 )
• QUAD ( type: esriFieldTypeString, alias: QUAD, length: 40 )
• LATITUDE ( type: esriFieldTypeString, alias: LATITUDE, length: 17 )
• LONGITUDE ( type: esriFieldTypeString, alias: LONGITUDE, length: 18 )
• DEC_LAT ( type: esriFieldTypeString, alias: DEC_LAT, length: 14 )
• DEC_LON ( type: esriFieldTypeString, alias: DEC_LON, length: 15 )
• ELLIP_HT ( type: esriFieldTypeString, alias: ELLIP_HT, length: 10 )
• POS_DATUM ( type: esriFieldTypeString, alias: POS_DATUM, length: 6 )
• DATUM_TAG ( type: esriFieldTypeString, alias: DATUM_TAG, length: 10 )
• POS_EPOCH ( type: esriFieldTypeString, alias: POS_EPOCH, length: 7 )
• POS_SRCE ( type: esriFieldTypeString, alias: POS_SRCE, length: 12 )
• ORTHO_HT ( type: esriFieldTypeString, alias: ORTHO_HT, length: 9 )
• VERT_DATUM ( type: esriFieldTypeString, alias: VERT_DATUM, length: 12 )
• VERT_EPOCH ( type: esriFieldTypeString, alias: VERT_EPOCH, length: 7 )
• VERT_SRCE ( type: esriFieldTypeString, alias: VERT_SRCE, length: 12 )
• GEOID_HT ( type: esriFieldTypeString, alias: GEOID_HT, length: 10 )
• GEOID_MOD ( type: esriFieldTypeString, alias: GEOID_MOD, length: 9 )
• DYNAMIC_HT ( type: esriFieldTypeString, alias: DYNAMIC_HT, length: 14 )
• MODEL_GRAV ( type: esriFieldTypeString, alias: MODEL_GRAV, length: 14 )
• N_ACC_HZ ( type: esriFieldTypeString, alias: N_ACC_HZ, length: 6 )
• N_ACC_EH ( type: esriFieldTypeString, alias: N_ACC_EH, length: 6 )
• N_ACC_STDN ( type: esriFieldTypeString, alias: N_ACC_STDN, length: 5 )
• N_ACC_STDE ( type: esriFieldTypeString, alias: N_ACC_STDE, length: 5 )
• N_ACC_STDH ( type: esriFieldTypeString, alias: N_ACC_STDH, length: 5 )
• N_ACC_CORR ( type: esriFieldTypeString, alias: N_ACC_CORR, length: 11 )
• POS_ORDER ( type: esriFieldTypeString, alias: POS_ORDER, length: 1 )
• VERT_ORDER ( type: esriFieldTypeString, alias: VERT_ORDER, length: 1 )
• VERT_CLASS ( type: esriFieldTypeString, alias: VERT_CLASS, length: 1 )
• DIST_RATE ( type: esriFieldTypeString, alias: DIST_RATE, length: 1 )
• ECEF_X ( type: esriFieldTypeString, alias: ECEF_X, length: 13 )
• ECEF_Y ( type: esriFieldTypeString, alias: ECEF_Y, length: 13 )
• ECEF_Z ( type: esriFieldTypeString, alias: ECEF_Z, length: 13 )
• SPC_ZONE ( type: esriFieldTypeString, alias: SPC_ZONE, length: 8 )
• SPC_NORTH ( type: esriFieldTypeString, alias: SPC_NORTH, length: 13 )
• SPC_EAST ( type: esriFieldTypeString, alias: SPC_EAST, length: 13 )
• SPC_CONV ( type: esriFieldTypeString, alias: SPC_CONV, length: 12 )
• SPC_CSF ( type: esriFieldTypeString, alias: SPC_CSF, length: 12 )
• UTM_ZONE ( type: esriFieldTypeString, alias: UTM_ZONE, length: 8 )
• UTM_NORTH ( type: esriFieldTypeString, alias: UTM_NORTH, length: 13 )
• UTM_EAST ( type: esriFieldTypeString, alias: UTM_EAST, length: 13 )
• UTM_CONV ( type: esriFieldTypeString, alias: UTM_CONV, length: 12 )
• UTM_CSF ( type: esriFieldTypeString, alias: UTM_CSF, length: 12 )
• STABILITY ( type: esriFieldTypeString, alias: STABILITY, length: 1 )
• FIRST_RECV ( type: esriFieldTypeString, alias: FIRST_RECV, length: 8 )
• LAST_RECV ( type: esriFieldTypeString, alias: LAST_RECV, length: 8 )
• LAST_COND ( type: esriFieldTypeString, alias: LAST_COND, length: 16 )
• LAST_RECBY ( type: esriFieldTypeString, alias: LAST_RECBY, length: 6 )
• SAT_USE ( type: esriFieldTypeString, alias: SAT_USE, length: 1 )
• MARKER ( type: esriFieldTypeString, alias: MARKER, length: 57 )
• SETTING ( type: esriFieldTypeString, alias: SETTING, length: 50 )
• STAMPING ( type: esriFieldTypeString, alias: STAMPING, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• NGS_RECOVER_URL ( type: esriFieldTypeString, alias: NGS_RECOVER_URL, length: 100 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
